Built-Up Roofing (BUR)

Built-up roofing (BUR), commonly known as “tar and gravel,” is a durable multi-ply roofing system designed for low-slope and flat roofs. It consists of alternating layers of bitumen—asphalt or cold app—and reinforcing fabrics such as fiberglass or felt. Most BUR systems are constructed with three to five plies and finished with a gravel, mineral, or reflective surfacing, providing excellent waterproofing, UV resistance, and long-term performance.

When properly installed and maintained, BUR systems typically deliver a service life of 20–30+ years, making them a cost-effective solution for many commercial and industrial buildings.

Key Aspects of Built-Up Roofing

ComponentsBUR systems include:

●     Bitumen (hot-applied asphalt or cold-applied adhesive)

●     Reinforcing felts (fiberglass, organic, or polyester)

●     Surfacing layers such as gravel/slag aggregate, mineral-surfaced cap sheets, or reflective coatings

Installation MethodBUR roofs are installed by layering reinforcing plies with bitumen to form a continuous, fully adhered waterproof membrane. The system is well suited for flat or low-slope commercial and industrial roofs.

LifespanA properly installed BUR roof typically lasts 20–30 years or longer, depending on installation quality, drainage, and maintenance.

Advantages

●     Excellent waterproofing through multi-ply redundancy

●     Strong UV protection, especially with gravel or mineral surfacing

●     Good resistance to foot traffic and hail

●     Frequently achieves Class A fire ratings

●     Generally lower lifecycle cost compared to some single-ply systems

Limitations

●     Heavy system weight may require structural evaluation

●     Installation is labor-intensive, especially hot-applied systems

●     Leak detection and repairs can be more complex due to multiple layers

Common Types of BUR Systems

1. BUR with Granulated Cap Sheet (2–3 Ply)

A base sheet—often mechanically fastened—is followed by one or two reinforcing plies mopped in hot asphalt or cold adhesive. A mineral-surfaced cap sheet is installed as the final layer.This configuration replaces gravel with a cap-sheet surfacing for a cleaner finish.

2. Classic 4-Ply Flood-and-Gravel BUR

A fiberboard or cover board is mechanically fastened to the deck, followed by four reinforcing felts mopped in hot asphalt. The system is flood-coated with asphalt and embedded with gravel or slag.This is the traditional heavy-duty BUR assembly.

3. Hybrid BUR / Modified Bitumen System

A 2–3 ply BUR base is installed and topped with a polymer-modified bitumen cap sheet.NRCA classifies this as a modified bitumen system, though it is often referred to in the field as a hybrid BUR due to its hot-mopped base construction.

How BUR Systems Are Built

Membrane ConstructionAlternating layers of bitumen and reinforcing felts—typically 36 inches wide—are installed to create a 3- to 5-ply membrane.

AttachmentMost BUR systems are fully adhered. Base sheets may be mechanically fastened, particularly over steel decks.

Surfacing Options

●     Flood coat with gravel or slag aggregate

●     Mineral-surfaced or glass-fiber cap sheets

●     Aluminum or elastomeric coatings for additional UV protection

Advantages in Colorado Front Range Conditions

●     Multi-ply redundancy provides superior leak resistance

●     Gravel-surfaced systems perform well under UV exposure, hail, and foot traffic

●     Strong fire performance, often achieving Class A ratings

●     Proven long-term performance in high-altitude, high-UV environments

Where Hybrid Systems Fit Best

A 2–3 ply BUR with a modified bitumen cap sheet combines:

●     The redundancy and thickness of BUR

●     The flexibility, durability, and cleaner surface of modified bitumen.
